Overall Length

• Fully Extended 94.5” (240.0 cm)
• Fully Retracted 82.5" (210.0 cm)

Overall Width

• Siderails Up 40” (102.0 cm)
• Siderails Down 37” (94.0 cm)

Weight Capacity

• 500 lb. (227 kg)

Height Range

• Low Position - Floor to Center of Deck 13" (33 cm)
• Low Position - Floor to Edge of Deck 17" (43.2 cm)
• High Position - Floor to Center of Deck 30" (76.2cm)
• High Position -  Floor to Edge of Deck 34" (86.4 cm)
• Maintains low height when placed in chair: Yes
• Headboard/push handles maintain same height regardless of patient surface height: Yes

Litter Positioning

• Head Section 0° to 60°
• Knee Section 0° to 16°
• Foot Section 0° to -27°
• Max Trend/Reverse Trend 15° / 10°
• Head and Trend Angle Indicators: Yes

Patient Surface

• Width 35.5" (90.2 cm)
• Length - Fully Extended 86" (218 cm)
• Length - Fully Retracted 75" (191 cm)
• Radiolucent Sleep Deck: No

Caster & Breaking System

• Caster Diameter 2” (12.7 cm)
• Four Wheel Braking: Yes
• Brakes Lock Both Rolling and Swiveling: Yes

All BedMed beds, mattresses, and parts are inspected and refreshed by expert technicians in the industry. The beds rolling into your facility can be used right away, just like you would with a new bed.

Our technicians go through a 30 step inspection on most products to ensure your items last for years to come.

Then main steps include:

• Safety & power check
• Functional components check
• Controls & indicators
• Battery maintenance
• Final QC
